The 24-30K hydraulic beavertail comes in bed lengths of 20-30' with a 10' hydraulic tail. It is equipped with 12 or 15K axles and is built on a 12" x 22# I-beam frame I-beam. Pintle and gooseneck couplers are both available. Electric or air brakes are available.
Product Features
GVWR24,000 or 30,000 lbs
Weight8,200 or 9,100 lbs
Length20' bed + 10' hydr. tail
Width102"
Frame12" x 22# I-beam
Unloaded Deck Height34"
Side Rails5 x 3 x 1/4" angle
Crossmembers3" channels
Fenders3/16" sheet
JackDual Speed, Dual 12K drop leg
Hitch2 5/16" adj. GN coupler
Safety Chains(2) 3/8" Gr. 70
Tie-DownsStake pockets and rub rail
Storage(2) 12 x 18 x 48 and (1) 12 x 12 x 36 toolbox
Axles12,000 or 15,000 lb.Dexter Oil Bath
SuspensionDexter Spring
Tire and Wheel235/80R-16E or 215/75R-17.5H duals
Decking2 x 8 No. 1 Treated pine
LightsLED flush mount
Elect. PlugRV plug
Finish and PaintBead blasted, acid washed, zinc rich primed, powder coated
Details
- 20-30' bed lengths available
- KTI hydraulic pump w/remote
- available in pull-type pintle hitch
- see options for other added features
Spec Drawings
