Single axle utility trailers are available in 60" - 81" widths and come standard with a 3,500 lb. idler axle. You have the ability to option this trailer out to add brakes, side rails, or other options. Available in 2,990 lb. to 7,000 lb. GVW configurations with ramps, or without ramps.
GVWR2,990 to 7,000 lbs.
Width60", 72", or 81" between fenders
Frame4 x 3 x 1/4 or 5 x 3 x 1/4 angle iron
Unloaded Deck Height18"
Crossmembers3 x 2 x 3/16 angle irons
FendersPurchased 14 gauge fender
Hitch2" coupler or 2 5/16" adj. coupler
Safety Chains(2) 3/8" Gr. 43
Axles3,500, 5,200, or 7,000 lb. Dexter Axle
Tire and WheelST205-75R-15D or ST225-75R-15D
Decking2 x 8 No. 1 Treated pine
LightsLED flush mount
Elect. PlugRV plug
Finish and PaintBead blasted, acid washed, zinc rich primed, powder coated
- Available with ramps or mesh gate
- Angle iron bump rail at front
- Optional side rails available
