The 24K tube tilt is a beast of a trailer, with no peers in its class, and is equipped with twin 12K torflex axles with 17.5 super single tires. The trailer is built with a heavy duty frame, while still maintaining a full 83" between the fenders and has an added standard option of fender guards. It is available with 2-8' stationary decks, with either 16' or 18' of tilt. Pull-type and gooseneck configurations are available.
Weight6,100 lbs. (for 24')
Length4, 6 or 8' stat. + 16' tilt OR 2, 4 or 6' stat. + 18' tilt
Width83" between fenders
Frame8 x 2 x 3/8 tube
Unloaded Deck Height25"
Side Rails5 x 5 x 5/16 angle (flush floor)
Crossmembers3" channels (12" ¢'s)
FendersHD Fully Welded 11 gauge
JackSingle 12K dropleg
Safety Chains(2) 1/2" Gr. 70
Tie-Downsstake pockets and (4) D-rings
StorageChain tray in tongue
Axles12,000 lb. Dexter
Tire and Wheel235/75R-17.5 16 ply (6,005 lb. load rating) super single
Decking2 x 8 No. 1 Treated pine
LightsLED flush mount
Elect. PlugRV plug
Finish and PaintBead blasted, acid washed, zinc rich primed, powder coated
- Only manufacturer who offers drop deck tilt with (2) 12K axles!
- Pallet fork holders and fender guides
- Flush floor
- True 83" wide between fenders
- Able to add bolt-on toolbox or spare tire mount on standard trailer
